cnc stone carving machine On Sale
EA-6090S is a small stone CNC router for a carved jade pendant-making field engineered to process the profiling, lettering, carving, chasing, and stone carving machine. Its working size is 600x900mm (2′ x 3′). It has a water coolant system for cutters composed of a nozzle, a water pump, and a water pan. This device’s function is to prevent shavings from sticking to the cutting edge and causing damage to the tool or carved project—a 6090 CNC gemstone carving machine for sale at a favourable price.
Application of cnc stone carving machine • Carved Artwork Made of Jade or Gem
• Production of carved jade jewelry and plates
Gemstone carving machine carved projects
Materials suitable for Jade, Granite, Marble, Neutral Stone, Aluminum, Sandstone, Artificial Stone, Solid Surface, MDF, Solid Wood, and more.
The X and Y axis utilize a fully enclosed dust-proof design, which can effectively prevent jade debris from falling into transmission components like racks and guide rails and further causing machine failures.
The water pan is located below the aluminum profile; it has an outlet at the back that is linked to the water pump to provide a mechanism for circulating the water.
For the cutters, it has a water cooling system.
Steel makes up the beam. When it comes to reducing and absorbing cutting forces, steel is superior to aluminum.
• Each user’s own electronic control panel.
• RichAuto A11, a handheld controller for the CNC system, permits re-carving after break points and power outages.
• The EA-6090S gemstone carving machine has a 3.0Kw water-cooled spindle specifically designed for working with stones.
• A centralized system lubricates all of the linear guides.
Gemstone Carving Machine Quick Details • Working Size: 2’x3′ – 600x900mm
• Water-cooled, 3.0Kw spindle
• Driver for Stepper & Leadshine DMA860H
RichAuto A11 controller for AutoNow
• Rolling ballscrew in the XYZ Transmission
•20mm HIWIN Linear Guides
Technical Parameter of cnc stone carving machine
|Type||Stone CNC Router|
|Simultaneous Axis Qty||Three|
|Mechanical Construction||Welded with steel tube, VSR treatment, finish by CNC machining center|
|Machine Bed||Aluminum profile & PVC layer & Water pot|
|Anti-Dust||On the X & Y Axis|
|Coolant System for Cutter||involved|
|X-Axis Stroke||23.6″ ( or 600mm )|
|Y-Axis Stroke||35.4″ ( or 900mm )|
|Z-Axis Stroke||4.72″ ( or 120mm )|
|Max. Feed Height||4.72″ ( or 120mm )|
|Electronic Spindle||Dedicated spindle for stone working, 3.0kw, 18,000RPM|
|Tool Diameter Range||3.175 ~ 12.7mm (1/8″ ~ 1/2″)|
|Inverter||3.7kw, FULING brand|
|Fast Travel Speed||15,000mm/min|
|Max. Feeding Rate||10,000mm/min|
|X Motion Drive||Stepper – 6.0N.m|
|Y Motion Drive||Stepper – 6.0N.m|
|Z Motion Drive||Stepper – 6.0N.m|
|X-Axis Transmission||Rolling ballscrew, 25mm|
|Y-Axis Transmission||Rolling ballscrew, 25mm|
|Z-Axis Transmission||Rolling ballscrew, 25mm|
|X Linear Guides||HIWIN, square type, 20mm|
|Y Linear Guides||HIWIN, square type, 20mm|
|Z Linear Guides||HIWIN, square type, 20mm|
|Numerical System||RichAuto A11 DSP handheld controller in English|
|Communication Code||G code (***.mmg)|
|Compatible Software||ArtCAM, Aspire, UcanCAM, Type 3, JD Paint, UG, MasterCAM|
|Other Electronics||Schneider, Omron, CHNT|
|Cables||High softness shielding cables for the whole machine|
|Workpiece Clamping Way||By clamps|
|Lubrication System||Central lubricating, manual type|
|Electronics Protection||Fuses, overload|
|Working Volts||AC220V/50 and 60Hz, Single Phase|
|Max. Power Consumption||6KW|
|Package Way||The complete machine in plywood case|
|Package Dimension||1440x1280x1690mm (3.11CBM approximately)|
